Features:

Driving assembly:House is made of grey cast iron HT200, and crank shaft, connecting rod, and gears are made of ductile cast iron.

Plunger:the 4th generation stainless alloy(PH-type).

Check valve:the 4th generation stainless alloy (GrMoFr),abrade-resisting and impact-resisting.

Pump block: stainless steel.

Plunger sealing:X4310 and PP spacer with heat-proof reaching 150°C.

Homogenizing valve: the 3rd special stainless alloy.

All the above-mentioned material are according with sanitary rules and suitable for CIP cleaning.

Specification:

Type and Specification	SRH2000-25
Rated volume of flow: L/H	2000
Max pressure: Mpa(=10bar)	≤25MPa
Rated working pressure: Mpa	≤20MPa
Feeding pressure	0.2-0.3MPa
CIP	150°C/≤1000CP
Motor power : KW	15
Machine size: m	1.2*0.9*1.4m
Weight	1500Kg
Driving traits	An eccentric shaft, symmetrical gears driving, splash-type lubrication, special alloy bush, main rolling bear and low noise
Pressure regulation	First-stage rated high pressure :Mpa	≤22
	Second-stage rated low  pressure: Mpa	≤8
