TT25 Series automatic baking machine is used for rolling sugar cones. It offer cones to the next process to be filled with ice cream. First it dispenses batter on the baking plates to prepare the wafers for shaping, then rolls them up, keep them in shape and unload finally. As one of the main ice cone baking machine, it has very good and reliable performance that reach international level, is widely exported over sea.

Main Export Area:

QIXIN brand sugar cone baking machine is a most famous manufacturer. Its products is widely exported to many oversea countries such as : Russia,Chile,Kyrgyzstan,Uzbekistan,Turkey,Argentian,Vietnam,Syria,French Polynesia, Egype, Peru, India etc.

Main Technical Parameters

Gas Heating Type Cone Baking Machine
Item		TT25	TT25-40	TT25-36	TT25-30
Baking Plate Numbers		45	40	36	30
Voltage		220V/380V	220V/380V	220V/380V	220V/380V
Input Total Power		1.5Kw	1.5Kw	1.5Kw	1.5Kw
LPG Consumption		4Kg/h      (4.2m³/h)	4Kg/h       (4.2m³/h)	5Kg/h       (5.5m³/h)	5Kg/h       (5.5m³/h)
Compressed Air Pressure		0.6MPa	0.6MPa	0.6MPa	0.6MPa
Weight of the Machine		3000Kg	3000Kg	3000Kg	3000Kg
Overall Dimension (cm)		320x270x190	320x270x190	320*270*190	320x270x190
Baking Cone Size(22.5°)	Diameter	42-48mm	46-52mm	50-58mm	58-68mm
	Length	100-115mm	115-130mm	130-145	140-165mm
	Production	2300-2500 pcs/h	2200-2400 pcs/h	2000-2200 pcs/h	1500-2000 pcs/h
Baking Cone Size(17.5°)	Diameter	38-44mm	/	/	/
	Length	110-125mm
	Production	2500 pcs/h
