The applications of KQZ-180D pneumatic water well drilling rig

KQZ-180D pneumatic water well drilling rig is suitable for drilling and geothermal drilling. It has the advantages of large diameter, deep drilling, fast track, flexible movement and wide use.

2.The specifications of KQZ-180D pneumatic water well drilling rig

Drilling hole diameter	100-219mm
Drilling depth	150m
Drilling angle	ground to 45-90°
Feed stroke	1500mm
Motor power	7.5kw
Rotary speed	0-78rpm
Wind pressure	0.8-2.1mpa
Air consumption	13-21L/min
Gross weight	600kg
