Specially designed for diesel purification.According to the characteristics of light diesel, we adopt high performance membrane filtration technology to refine the diesel,as well as to remove the impurities, colloid and water from oil. As a result, the quality level of diesel can be upgraded.



Technical Index:

Model Type: JY-DL60

Flow Rate: 50~60 tons/h (Depends on the quality of oil)

Filtration Precision: 2,5,10,15,20μm （According to system requirements）

Filtration Material: Jingyuan Polymer Membrane Material(Various types,and can be used repeatedly after washed )

Working Pressure: 0.2~0.35 Mpa

Filtration Efficiency(≥4μm):98%

Pre-filtration: Y (Two levels)

Pipeline Diameter: DN100(4′)

Suitable Oil: Light diesel, aviation kerosene

Measurement: 3250*1700*2450mm



·Solve the oil turbidity caused by micro particulates, impurities, water and colloid.

·Remove lots of water and sediment from distillation diesel and catalytic kerosene.

·Diesel becomes clear and bright after refined by membrane elements.

·High-efficiency, energy-saving and environmental protection.

·Modular design make installation and maintenance more convenient.



Application:

Be suitable for large oil depot, diesel refinery, railway station oil depot, large scale generator unit, military industry,nuclear power, power plant, oil extraction plant, oil loading filtration and oil unloading filtration and so on.



Quality Guarantee and Reliability:

＞ All of Jingyuan membrane filters are produced with high quality, and meet the manufacturing standard.

  As a result,our filters will run efficiently and safely.

＞ All products are strictly designed and manufactured in accordance with ISO9001 Quality Control System.





For more information, please contact 139 0405 2025 or 024-86530244

Jingyuan Membrane Filtration —— Different from traditional filtration and purification.
