Tank

Transporting Media

Dimethylmethane, Liquid Ammonia, Liquid SO2, LPG, Butane

Shape

Round Shape

Total Volume(m3)

56CBM

Tanker Body Steel Sheet

Q235A/14mm

End plate

Q235A14mm, by punching

Parts for Tank

Manhole cover

3 sets of 500mm/Q235 manhole fixed on top of Tank, with breather valve

Unloading valve

2-3 sets of DN80 fixed at button of Tank

Pipeline at button of tank

4”seamless steel tube/Q235

Labeling system

Oil Type Indication

Anti-static electricity system

pulling, wire carrier, sheet copper (6 sheet-standard layout)

Other Part

Ladder

1 unit at front of Tank

Guard on top of Tank

Zinc galvanized –guard-net

Oil hose box

Circular single hole tube, 1 unit on each side

Oil hose

2 unit, 3” x 6m size in black rubber

Side guard

cross bar-structure

Rear button guard

Fixed type

Work tank deck

Box type

Fire extinguisher box

2 unit at the back of each side

Mud guard

Steel structure in trapezoid form

Lights and wire

24V, 7 coils with lights for parking, reverse, instruction, head lamp and end lamp

Chassis

Main Beams

Heavy duty and extra durability designed; Opting for high tensile steel Q345B,welded by automatic Submerged-Arc processes

Axle

3 axle ;BPW brand

Landing Gear

JOST Two-speed, manual operating, heavy duty landing gear

King Pin

JOST 2”standard bolt-in king pin

Suspension

German design mechanical suspension

Pneumatic Braking System

WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks.

Wheel rim

8.25R22.5 wheel rim

Tire

11R22.5 tubeless tire with one spare tire

Painting

Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
