psa nitrogen generator:
1.N2 purity:99-99.999%
2.N2 capacity:40-3000

99-99.999% purity Pressure Swing Adsorption PSA Industry Nitrogen generator

Product

Product Details

Process Principle:

PSA nitrogengeneration adopts highquality carbon molecular sieve as adsorbent. Under the certain pressure,

it utilizes the differences of adsorption when nitrogen molecules and oxygen molecules are through the carbon

molecular sieve according to the diffusion rate of oxygen is larger than that of nitrogen in the air and the

inherent physical characters of carbon molecular sieve. The two adsorption towers A&B are in the process of

alternately cycle, pressure-rising adsorption and depressurization desorption to separate oxygen and nitrogen to obtain required purity nitrogen by open and close of pneumatic valves controlled by PLC.

Technical Characters:

1. Highperformance: The new generation PSA system with low energy consumption applies balancepressure

process of differential type to recover energy and separate oxygen and nitrogen in the air. It has the

advantages of high efficiency and low energy consumption. The filling and compaction of molecular sieve is

finished in the professional environment with professional manner.

2. Stableperformance: The service valves apply the special valves which are free of trouble for frequent

switching within 2 million times. It can ensure secure and stable operation for the new high efficiency integrated

PSA system.

3. Easyoperation: Siemens S7200 programmable logic controller (PLC) is applied to control the equipment.

So the operation is extremely simple and nitrogen can be output in stable pressure. The emptying device of

unqualified nitrogen can really ensure the quality of nitrogen for customers to use, and purity and flow of

nitrogen can be automatically recorded. It is very convenient to find the working state at any time. It can be

realized that no one is needed to operate and remote monitor the equipment in the whole process.

Main Technical Parameters of PSA CMS Nitrogen Generator:

Model	N2 Purity %	N2 Capacity Nm³/h	Air Consumption m³/min	Dimensions mm (L×W×H)
ZR-40	99	40	1.8	1900×1400×1800
	99.5		2.0	2000×1450×1900
	99.9		2.8	2100×1500×2050
	99.99		3.7	2200×1500×2350
	99.999		6.0	2600×1800×2550
ZR-50	99	50	2.1	2000×1500×1900
	99.5		2.5	2050×1450×1850
	99.9		3.3	2100×1500×2250
	99.99		4.7	2500×1700×2500
	99.999		7.5	2700×1800×2600
ZR-60	99	60	2.8	2050×1450×1850
	99.5		3.0	2050×1500×2100
	99.9		4.2	2200×1500×2250
	99.99		5.5	2550×1800×2600
	99.999		9.0	2750×1850×2700
ZR-80	99	80	3.7	2100×1500×2000
	99.5		4.0	2100×1500×2150
	99.9		5.5	2500×1700×2550
	99.99		7.5	2700×1800×2600
	99.999		12.0	3200×2200×2800
ZR-100	99	100	4.6	2100×1500×2150
	99.5		5.0	2200×1500×2350
	99.9		7.0	2650×1800×2700
	99.99		9.3	2750×1850×2750
	99.999		15.0	3350×2500×2800
ZR-150	99	150	7.0	2450×1470×2400
	99.5		7.5	2550×1800×2600
	99.9		10.5	2750×1850×2750
	99.99		14.0	3300×2500×2750
	99.999		22.5	3500×3000×2900
ZR-200	99	200	9.3	2600×1800×2550
	99.5		10.0	2700×1800×2600
	99.9		14.0	3300×2500×2800
	99.99		18.7	3500×2700×2900
	99.999		30.0	3600×2900×2900
ZR-300	99	300	14.0	2700×1850×2700
	99.5		15.0	3150×2150×2750
	99.9		21.0	3500×2700×2900
ZR-400	99	400	18.6	3200×2200×2800
	99.5		20.0	3350×2500×2800
	99.9		28.0	3800×2900×2900
ZR-500	99	500	23.3	3350×2500×2800
	99.5		25.0	3500×2700×2900
	99.9		35.0	3800×3000×3000
ZR-600	99	600	28.0	3500×2700×2850
	99.5		30.0	3500×3000×2900
	99.9		42.0	4000×3000×2900
ZR-800	99	800	37.5	3600×2900×2900
	99.5		40.0	3600×3000×2900
	99.9		56.0	4000×3500×3000
ZR-1000	99	1000	47.0	3600×2900×2900
	99.5		50.0	4000×3000×2900
	99.9		70.0	4200×3550×3000
ZR-1500	99	1500	70.0	4000×3500×2900
	99.5		75.0	4200×3500×2950
	99.9		105.0	4500×3800×3000
ZR-2000	99	2000	94.0	4200×3500×3000
	99.5		100.0	4300×3800×2950
	99.9		140.0	5000×5000×3000
ZR-3000	99	3000	140.0	4500×3800×2950
	99.5		150.0	4800×4800×3000
	99.9		210.0	6000×6000×3000
