- Packaging Details：Wooden Case Packing accord with export standard. After inspection by the quality control department, passing inspection, the machine comprehensive clean-up, and then start packing. First desiccant is placed in the machine And then around the machine with 6 cm thick foam board, winding stretch film for reinforcement, and then add the bubble film. Machine packed in wooden case, and then the metal strip reinforcement. Product packed in containers, depending on the product to be reinforced.
- Delivery Time：within10 working days after we confirmed for convection oven
convection oven
convection oven Fearture:
1.The convection oven is made of Stainless steel,Outside and inside all in stainless steel.
Perfect heating and steam spraying system.
2.The Oven can be heated by Gas and electric, we call it Gas heated Convection oven or Electric
Hot Convection Oven.
3. Instant warming system
4. Automatic circulation of warm air by convection to generate maximum baking heat.
5. The convection oven is with Microcomputer digital system.
6. The convection oven has double layer safety glass door and halogen light inside to make one
able to see the paste/dough throughout the baking process.
7. The powerful automatic timer system, which controls the volume of steam at required set period
of baking.
8. Lower energy consumption makes the convection oven very popular in different size of bakeries
9. Stable under all climatical conditions.
10.If necessary,you could choose to add a proofer room together.
convection oven specification:
|
Model
|
C5-40/60
|
C10-40/60
|
PV16-40/60
|
|
Item (cm)
|
40*60
|
40*60
|
40*60
|
|
Trays
|
5
|
10
|
16
|
|
Pitch (cm)
|
8.4
|
8.4
|
8.4
|
|
Weight (kg)
|
125
|
180
|
80
|
|
Temperature
|
0-300°C
|
0-300°C
|
0-50°C
|
|
Dimensions
W*D*H(cm)
|
80*110*67
|
80*110*107
|
80*110*92
|
|
Power (kw)
|
9
|
18
|
1.2
|
|
Voltage (V)
|
3ph-220/380V
|
3ph-220/380V
|
220V
|
|
Water pressure
|
0-3bar
|
0-3bar
|
0-3bar
|
Pictures for convection oven
