ice crusher

Model:KS-168

Voltage: 220V/50HZ

Power: 250W

Size: 380*300*460mm

Capacity: 6kg/min

Weight: 20kg

Performance and characters (Instruction):

1.Open the lid and sweep the slot. And then check the blades to be stably fixed.

2.Check the power cable. Turn off the switch and plug the power.

3.Open the lid of the water-cooling machine and then put some ice-blocks before close the lid.

4.Press the start button.

5.Modulate the blade according to the need of the shapes of the ice.

6.Diameter of the ice-block of 4-5cm is preferable,.

Attention:

1.The voltage should be the 220V

2.The lid should be equipped with protection device, which makes this machine impossible to operate if the lid has not been closed even if the start button has button pressed.

3.The machine should be fixed at a flat place and the quantity of the ice should be thrown into the slot uniformly to prevent the body from shaking.

4.The quantity of the ice should be lower than the place that is high than the red line by 1cm in the slot.

5.The cleaning process should be operated by clothes but not by water.

6.Every the water in left in the slot should be cleaned after using.

7.Pay attention to the blade when cleaning, so that the fingers will not be injured.

8. Do not detach the parts of the machine freely.

                                                                                  Scraper contrast

our  factory'  Scraper is once-forming                                        other factory' Scraper is Foundry casting

                                                      Comparison of internal chassis

 ours' is made of 304 stainless steel                                   other' s is made of aluminum

                                                                           Caliber contrast

Ours' is 15cm                                                                                             others' is 11cm
