HPYL series hydraulic oil press machine can directly squeeze out the oil when you add the materials into the barrel. And you will get the oil after 3-5 minutes.The cold/hot press hydraulic oil press machine is widely used for various oil seeds, such as sesame, walnut, peanut, flax seed, rape seed, etc.
Meanwhile, this oil mill machine is the patented product improved by our factory,the more advanced veg. oil processing machinery, With the characteristic of the simple structure, easy operation, energy saving, low noise, high rate of oil, adaptability and continuous operations.



Model	HPYL-180	HPYL-200
Dimensions	2300*810*2300mm	2700*1000*2720mm
Weight	1800KG	2500KG
feeding motor with reducer	2 kw-3 pole	2.2kw-4 pole
residue oil of cake	<7%	<7%
Capcity	1.3 t/h	1.7 t/h
Motor power	30KW-4 pole	37KW-6 pole



1.Working principle:This oil mill machine uses the poer of the space change for the material in the chamber and the driving force from the scre shaft as well as the resistance from the tooth curve in the pressing ring.The friction force from material pressing produces big pressing power,then oil-segregates from the material and discharges from the pressing bar gap and pressing ring groove.
2.Structure: This oil mill machine consists of five main parts,including gearbox,press case,hopper,pressing screw and main body.
