POE Injector For IP Cameras PT-PSE100GF

PT-PSE100GF is a single port midspan Injector with 2 Pair PoE up to 15.4 watts of power at 48Vdc, 0.32A amp.

Designed for the AF powered 15.4W PoE Powered Devices (PDs), such as IP Cameras, wireless APs, Microwave radio, IoT application, door locks, displays, POS, and information kiosks, It supports 10/100/1000Mbps of data rates. Fully comply with IEEE802.3af devices. Equipped detecting chip inside, which will detect and classify PD before powering it, protecting non PoE device.

We provide high quality PoE Injector, outdoor PoE Injector, POE for DIN Rail, dc poe injector and soon.

Enclosed in an IP40 fire retardant plastic case, designed for indoor use, installation with Wall-mounted. It operates with a wide input voltage of 100-240Vac, 50 or 60 Hz. The effective distance limitation of 100 meters over Cat5e/Cat6 cables.

Can be extended with the PoE Injector for wireless APs PT-PEX-01G-OT(Outdoor or Indoor PoE Extender).

We are PoE Injector supplier and more information you can view here

Parameter	Description
Key Features
Part Number	PT-PSE100GF
Ports   condition	LAN Port*1,AC Input   Port*1, PoE Output Port*1
Regulatory   Compliance	IEEE802.3af RoHS Compliance WEEE Compliance
Pass Through   Data Rates	10/100/1000 Mbps
PoE Injector Output	Pin Assignment and Polarity: 4/5 (+), 7/8 (–) Output Power Voltage: 48Vdc User Port Power:15.4W Guaranteen
Input	Input   Voltage: 100-240Vac Frequency: 50/60Hz Typ
Working   Environment	Operating   Temperature: 0℃ to 40℃ Operating Humidity: 20% to 80%, non-condensation Storage Temperature: -20℃ to 70℃ Storage Humidity: 10% to 90%, non-condensation Operating Altitude: up to 2000meters
AC Surge   Protection	Line-Earth   1.2/50us (8/20us): 6KV Line-Line 1.2/50us (8/20us): 4KV
Mechanical   Characteristics	Case: plastic Color: Black Mounting: Wall-mounted IP Rated: IP40 Connectors: Shielded RJ-45*2 Size: 134 X 56X 33mm Weight:170g(0.37lb)
LED Indicator	Power   Indicator: Green PoE Load Indicator: Green
Warranty	2 year
Safety   Approvals	CE,   FCC
