The scanning mirrors are light weight rectangular mirrors that used for high speed two-axis laser scanning system. The dimension for each mirror have been calculated accordingly with the laser beam size. The mirror has high reflectivity of 99.5% or above. The scanning mirror usually mounted on to a galvanometer for scanning purposes. For two axis scan mirror, commonly the Y mirror has a bigger size compared with the X mirror. This is due to the fact that the X mirror is used to scan the Y mirror rather than the object directly. Application: Optical coherence tomography, Laser projection, Laser marking, Confocal microscopy.
Part No.: GIAI-AOI-10-10.6
Incident spot diameter: 10mm
Wavelength: 10.6μm
Type: CO2 laser
Light incident angle: 45° ± 15mm
Coating: HR@10.6μm
Reflection: R> 99%@10.6μm
