QN Series roundness vacuum concentration tank Hit count 1069

FOB Reference Price / Min.Order Quantity : Get Latest Prices

Processing Time:1 Days - 60 Days

Packaging Details: STANDARD EXPORTING PACKAGE

Port: Shanghai / Shenzhen / Qingdao / Ningbo / Other

Payment Terms: L/C , T/T , other

Product Details Company Profile

The roundness concentration tank, consisting of main body,condensator,gas-liquid separator and liquid receiving barrel. Serves to concentrate,distill the material liquid and reclaim organic menstruum in the pharmacy,foofstuff and chemistry.The concentration under reduced pressure brings short time of concentration and prevent the destruction of the effective content in the thermal sensitive material.The fact that the part in contact with the material is made with stainless steel brings qualified anti-corrosion performance,meeting with the GMP standard.

Technical parameters:

type specifications		QN-300	QN-500	QN-700	QN-1000
Evaporation capacity(kg/h)		70	120	145	195
Nominal volume		300L	500L	700L	1000L
Jacket pressure		0.09Mpa
Vacuity		500～620mmHg
Heating area		1.3	1.6	2	2.8
Condensating area		2.4	3	3.5	4
equipment weight (kg)		380	450	630	950
External dimensions	L	1900	2030	2100	2335
	W	1100	1200	1300	1520
	H	2300	2500	2600	2765
