Fixed Mount Scanner FM100
Fixed Mount Scanner
IR/Light Triggers Fixed Mount Scanner
Designed for OEM applications, this high performance fixed mount barcode scanner can easily be integrated into various solutions such as kiosks, ticketing machines, (reverse) vending machines and many more.

Ease of integration
Compact and easy to integrate design. The small form factor enables easy integration into various solutions. The NLS-FM100-M has an IP54 rating meaning it is dust -and water resistant.

Advanced Technology
Armed with core technology UIMG, which is independently designed and manufactured by Newland Auto-ID.
technology includes the optical, CMOS, digitizer, decoder, image processing & embedded systems. The scanner supports all global standard 1D barcode symbologies. Its reading performance exceeds global standards. By using the accessories provided, the user can ideally set up the scanner to its user environment.

Performance
Image Sensor		Linear imager
Resolution		2500
Interface		RS232, USB 1.1
Symbologies		Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ISBN/ISSN, Code 93, UCC/EAN-128, GS1Databar,etc.
Precision		≥ 5mil( Condition: PCS=0.9, testing code: Code 39)
Depth of Scan Field		40mm-430mm
Print Contrast Signal		≥ 30%
Sensitivity**	Pitch	±65°@ 0°Roll and 0° Skew
	Roll	±30°@ 0°Pitch and 0° Skew
	Skew	±60°@ 0°Roll and 0° Pitch
Illumination		0 ~ 100,000 LUX
Light Source		LED(622 nm - 628 nm)
Light Intensity		265 LUX (130 mm )
Mechanical/ Electrical
Power Consumption		1.25W
Voltage		DC 5 V
Current	Max	250 mA
	Working	170mA
	Idle	65mA
Dimensions		49.0 37.0 26.0 mm
Weight		70 g
Environment
Operate Temperature		-5°C - +45°C
Storage Temperature		-40°C - +60°C
Humidity		5% - 95% （non-condensing）
Certificates
FCC Part15 Class B, CE EMC Class B
Accessories
Cable	RS232 Cable	Equipped with a power connector; used to connect the NLS- FM100-M to a host device.
	USB Cable	Used to connect the NLS-FM100-M to a host device.
Power Adapter		Used to provide power for the NLS-FM100-M. Output: DC 5V, 2A; Input: AC100~240V, 50~60HZ.
**Test Conditions: Code39: 3 Bytes ; Resolution = 10mil; W:N = 3:1 ; PCS = 0.8 ; Barcode Height = 11mm; Distance = 120mm; T=23°C; Illumination= 200 LUX
