Stabilized Soil Mixing Plant

It main technical features are as follows:

The universal modular design makes installation easy and reposition speedy.

The double-horizontal-shaft forced mixing produces a strong mixing force and can realize rapid and even mixing.

The batch feeder is equipped with press-forming steel plates which are rigid and good-looking.

It uses whole sets of high-quality imported electric components made by world-famous suppliers like SCHNEIDER, SIEMENS and OMRON, which are excellent and endurable. There are automatic and manual operating modes for your choice and both are flexible and easy. Double operation of computer and control table are realized with much convenience and reliability. The double operating mode through computer and control board is easy and reliable.

Abnormal working conditions and breakdowns can be automatically detected and indicated through words, sound, light and warning, which makes it easy to find and fix them.

[Stabilized Soil Mixing Plant Main technical parameters]

Model		WCB300	WCB400	WCB500	WCB600
Rated productivity (t/h)		300	400	500	600
Stone container volume(m³)		3×12	3×12	4×15	4×15
Cement measuring container volume(m³)		7	7	9	9
Finished material container volume(m³)		8	8	10	10
Distributing precision	Aggregate	±3%	±3%	±3%	±3%
	Cement	±1%	±1%	±1%	±1%
	Water	±1%	±1%	±1%	±1%
Aggregate grain size(mm)		≤60	≤60	≤60	≤60
Material loading height(m)		3.9	3.9	4.2	4.2
Material unloading height(m)		3.1	3.1	3.1	3.1
General power(kw)		108	118	123	139
