Packaging & Delivery

Packaging Details:	Container order, remove the canopy and put two layer in the container and holded with steel
Delivery Detail:	15~20 days

EEC 4kw Motor Four Wheels Golf Course Electric Golf Cart for 6 People



Dongfeng Electric Vehicle Co.,Ltd, branch company of Dongfeng motor corperation, which ranks 109th in Fortune Global TOP 500. We have more than 10 years design, study and manufacture experience in Electric Vehicle, especially for Golf Cart.

Humanized design fits your unique needs and delivers hours of trouble-free driving pleasure.

1. High quality thermoplastic bodywork is UV resistant, fade-proof, and dent prevent,it is no need extra painting.

2. CE certified for whole carts and for main parts also passCE, UL,for different carts

3. A Long, StrongWarranty.Dongfeng Motor's aftersale networks are spread all over the world.Gurantee customers can get parts and maintenance easily.



Bodywork
Frame	steel reinforced (Guarantee normal use for 10 years)
Body	High-strength and impact resistant composite material
Body Color	Champagne color, Coral red, Pearly white
Bodywork parameters
Overall length:	3620mm
Overall width	1200mm
Overall height (with suntop)	1870mm
Wheel base	1670mm
Front wheel tread	880mm
Rear wheel tread	970mm
Width of seat	50cm
Seating capacity	4
Turning radius (m)	4.5m
Maximum speed	30km/h
Power system
Driving system	Gear-driven, Stepless speed change, Electric rear drive
Motor	KDS(3kw)  DC Separately Excited(imported)
Battery	TROJAN(T-875) 8V×6
Charger	48V 25A computer controlled charger
Speed controller	CURTIS Controller 1266-5201
Gear ratio	12.49
Maximum climbing ability	30%
Steering and Suspension
Steering system	Rack and pinion steering system, automatic rocker compensating function
Front suspension	Macpherson independent suspension
Rear suspension	2 slices of leaf spring suspension + cylinder hydraulic shock absorber
Brake system	Rear drum brake + parking brake
Automatic speed control system	Controller+ Induction motors
Autobrake System	Controller+ Induction motors
Braking distance	≤4.5m
Wheel & Tyre	18X8.50-8,6layer superior tread tire











Warranty
Item No.	EQ9022-V4
Warranty	2 years

Dongfeng Electric Vehicle Co., Ltd.
