Baffle Range Hood Filter - Stainless Steel, Aluminum, Galvanized Steel

Baffle range hood filter, also called baffle grease filter or grease baffle filter, is a kind of range hood filter in a range hood ventilation system. Baffle range hood filter is made of aluminum, stainless steel and galvanized steel. The layers of roll-formed baffles are designed to catch oil smoke, prevent oil and flame, making the kitchen clean and safe. Baffle range hood filter has a highly effective (approx. 94%) oil smoke purification and fireproof function. Three or more hood filters are needed in a range hood and they are widely used in domestic kitchen, kitchens in restaurant, dining hall in government, school, etc.

A stainless steel baffle grease filter fixed by sturdy frames with rivets

495mm W × 495mm H × 48mm D stainless steel baffle grease filter

An aluminum baffle grease filter has handles on both vertical sides of the frame for easy assembly and removal

406mm W × 254mm H × 50mm D aluminum baffle grease filter has two handles for convenient removal and holes on frame for easy catching oil

Detailed structure of aluminum baffle range hood filter handle welded in the middle of the frame

The handle welded on the frame provides convenience for range hood filter assembly and disassembly

A detailed display of sturdy stainless steel baffle range hood filter frame

The sturdy range hood filter frame stabilizes range hood filters

Baffle grease filters are wrapped in polybag, then they are put into the carton and closed by fixed belt

Strict packaging ensures baffle grease filter's safety

Structure
Baffle grease filter consists of two layers of stainless steel, aluminum or galvanized steel V-shaped baffles and fixed by sturdy frame with heavy rivets. Baffle grease filter can also be constructed with handles for easy removal. The handles are available in lock type handle, bail handle and rigid handle.

A sketch that displays lock-handle, bail-handle and rigid handle respectively

Three kinds of handles are used for assembling and removing range hood filters

Operation
When the air goes through the V-baffle system, it undergoes a series of compression, expansions and pressure changes. The heavy grease is deposited safely and quickly on the baffles while the grease-free air passes through the filter and up to the exhaust duct. The baffle's smooth surface enables the collected grease to run off into collection troughs without dripping on food, utensils or burner surfaces.

Cleaning
The baffle grease filter needs cleaning regularly to make sure it works well. It can be soaked in hot water and washed using detergent, or can be washed in the dishwasher.

Applications:
Baffle range hood filter is mainly installed to range hood system widely applied in domestic kitchen, restaurant kitchen, dining halls in government, school and many places where there are kitchens.
