diesel truck forklifts

Diesel Forklift

material handling forklift,High Efficiency diesel forklift

The selected engine fully complies with national and international emission standards, with strong power, low fuel consumption, and low noise;
The perfect combination of high quality engine and gearbox. Significantly increased traction, climbing force and lifting speed. Improve the working efficiency of the forklift.

PRODUCT INTRODUCTION
The FD15Z and FD18Z are mini diesel forklift with very small payloads. They are very flexible and powerful, making them ideal for small cargo factories. The selected engine fully complies with national and international emission standards, with strong power, low fuel consumption, and low noise; The perfect combination of high quality engine and gearbox. Significantly increased traction, climbing force and lifting speed. Improve the working efficiency of the forklift.

Features		FD15Z	FD18Z
Power	--	Diesel engine	Diesel engine
Rated Capacity	kg	1500	1800
Center of load	J(mm)	500	500
Lifting height	h1(mm)	3000	3000
Free lifting height	h3(mm)	130	130
Forks L×W×H	L5×W×T(mm)	920×100×35	920×100×40
Tilt Forward/Backward	--	6/12	6/12
Min. turning radius	R1(mm)	2060	2060
Min right angle stalking width	Ra(mm)	3780	3780
Min. ground clearance(Mast)	m(mm)	105	105
Overhead guard height	h4(mm)	2040	2040
Front overhang	L3(mm)	400	400
Rear overhang	L4(mm)	450	450
PERFORMANCE
Max. traveling speed(loaded)	km/h	14.5	14.5
Max. lifting speed(loaded/empty)	mm/s	460/500	460/500
Drawbar pull/Gradeability	kN/%	16/20	16/20
SIZE
Overall length with fork	L1(mm)	3170	3170
Overall width	W1(mm)	1086	1086
Mast lowered height	h2(mm)	1990	1990
Mast extended height	mm	4025	4025
CHASSIS
Tire(Front)	---	6.5-10-10PR	6.5-10-10PR
Tire(Rear)	---	5.00-8-10PR	5.00-8-10PR
Wheelbase	L2(mm)	1400	1400
Tread width(Front/Rear)	S/P(mm)	890/920	890/920
Curb weight(None-load)	kg	2680	2890
ENGINE
Battery(Voltage/Capacity)	V/Ah	12/90	12/90
Engine type	－	4B4-45V32	4B4-45V32
Rated power	kw	32/2600	32/2600
Rated torque	kw	138/1950	138/1950
Displacement	L	2.27	2.27
