Options & Specifications.

Note:

Outside Dimension of Truck

6070mmLx2010mmWx3050mmH

Chassis Brand & Model

Isuzu (NKR77LLEACJAY)

Engine Model

4KH1-TC

Engine Power (kw)

96

Engine Displacement

2999

Fuel Type

Diesel

GVW(kg)

4861

Tare Weight(kg)

3210

Rated Payload(kg)

1511

Front/Rear Suspension (mm)

1015/1620

Approach/departure Angle(º)

24/16

Wheelbase (mm)

3360

Front/Rear Tread (mm)

1504/1425

Axle No.

2

Maximum Speed (km/h)

98

Leaf Spring No.

8/6+5

Tyre Specification & No.

7.50-16 (6)

Steering Wheel

LHD

Power Steering

Yes

Air Conditioner in Cab

Yes

Refrigerated Truck Body Size (Outside)

4350mmLx2000mmWx 2130mmH

Refrigerated Truck Body Specifications

Adopt FRP sheet in two sides and PU foam in the core. The truck bodies equipped with rolling door in back, M type flooring, lighting system etc..

Rolling Door

Made-in-China

Useable Size of Opening of Rolling Door

1680mmWx1700H

Refrigeration System:

Refrigeration Unit Brand

Thermoking

Refrigeration Unit Model

KV300

Driven Type

Truck Engine Driven

Electricity Standby

No
