Cast Iron Globe Valve

Tanghai valve offers a wide variety of designed multi-turn valve configurations in stainless and carbon steel, along with virtually every special alloy required for difficult fluid compositions and high-pressure, high-temperature applications.

We provide cast and forged globe valves that are designed, engineered and manufactured in strict accordance with national piping standards.

Application：Petroleum Refineries, Chemical processing plants, Power generating plants.

Design and Manufacture Conform to MSS SP-85

Flange dimensions Conform to ANSI B16.1 CLASS125

Face to Face dimensions Conform to ANSI B16.10

Testing Conform to MSS SP-85

Sutiable Media: Water, Oil, Gas

MATERIALS OF PARTS

Number	Part Name	Material
1	Body	ASTM A126 B
2	Seating ring	Brass
3	Disc ring	Brass
4	Disc ring	ASTM A126 B
5	Locking nut	Brass
6	Stem	ASTM A276 420
7	Body gasket	08≠Steel+Graphite
8	Packing	Graphite
9	Bolts	Steel
10	Packing gland	ASTM A536 65-45-12
11	Bonnet	ASTM A126 B
12	Stem nut	Brass
13	Handwheel	ASTM A126 B
14	Bolts	Steel



SIZE	2"	2.5"	3"	4"	5"	6"	8"	10"
L	203	216	241	292	330	356	495	622
D	152	178	191	229	254	279	343	406
D1	120.7	139.7	152.4	192.5	215.9	241.3	298.5	362
D2	71.45	82.6	101.6	133.4	152.4	181	234.95	292.1
b	15.8	17.5	19.1	23.9	23.9	25.4	28.6	30.2
n-d	419	419	4-19	8-19	8-22	8-22	8-22	12-25
