Quick Details



• Place of Origin: Jilin, China (Mainland)
• Brand Name: Zhongke
• Model Number: HB1104
• color: yellowish
• size: 2mm*30mm*360mm
• Tensile strength: ≥1Kpa
• Elongation at break: ≥1000%
• Volume resistance: ≥1*1011Ω*cm
• Dielectric strength: ≥15kv/mm
• Dielectric constant: ≥13
• Adhesive to PE: 10N/cm
• Oxygen resistance: pass
• Heat shock(105℃): pass

• Min.Order Quantity: 100 Kilogram/Kilograms customers requires
• Supply Ability: 500 Kilogram/Kilograms per Day customers requires
• Port: Dalian port



Package and Delivery





Packaging Details:	Isolation paper Inner packing: Plastic bag Outer packing: Carton with lettering, inner lining plastic bag
Delivery Detail:	within 20 days after receving the T/T or L/C



Features



1.good bonding strength to the tubing of aluminum,copper,lead and tubing for oil removal and  insulation tubing.

2.insulated cables connectors with good air-tightness,sealing,bonding,weathering resistance, ageing resistance,and electrical property.



Application



1.Butyl based mastic tape is made from non-toxic butyl composite. Self-amalgamating and solvent free make the mastic effectively used in sealing cable joints and terminations to provide waterproof and void filling.
2.The specially designed insulation give excellent compatibility with  polymeric cables.
3.Suitable for applications in power cable termination and joint 15kv,24kv,36 kv.
4.Maximum service temperature:90 degree.
5.Standard color: light yellow.



Specifications



property	Testing method	Typical data
Tensile strength	GB/T 528-92	≥1Mpa
Elongation at break	GB/T 528-92	≥1000%
Volume resistance	GB/T 1692-92	≥1*1011Ω*cm
Dielectric strength	GB/T 1695-81	≥15KV/mm
Dielectric constant	GB/T 1693-81	≥13
Adhesive to PE	GB/T 2790-95	10N/cm
Oxygen resistance	-	pass
Heat shock(105°C)	-	pass
