Electric heating reactor,Industrial heating equipment

FOB Reference Price / Min.Order Quantity : Get Latest Prices

Processing Time:1 Days - 60 Days

Packaging Details: STANDARD EXPORTING PACKAGE

Port: Shanghai / Shenzhen / Qingdao / Ningbo / Other

Payment Terms: L/C , T/T , other

Product Details Company Profile

Reactor is widely used in the reaction, evaporation, concertration, composition, extraction, polymerization, mineralization of chemical, pharmaceutical, dye, pesticide, organic synthesis, petroleum, food additives, defense industry and scientific research etc.

DESCRIPTION

1.material : stainless steel ,carbon/mild steel ,aluminium

2.Volume:30-50000L

3.Heating methods: electrical heating , steam heating ,thermal oil heating

4.Type: jacket or outer-coil(limpet coil)

5.Agitator: paddle type, anchor type, ribbon type,gate type,etc.

Working Principle:
The working principle of the electric heating reactor is to put the electric heater into the heat transfer oil in the jacket, using the heat transfer oil as the heat carrier to heat the material in the reactor.

Model#	Practical Volume	Electric Heating Power	Volume of Oil in Jacket	Size of Inner Boiler(mm)	Size of Outside Boiler(mm)	Distance between center of screws on the support	Outer diameter (mm)	Decelerator Model#	Power of Motor(n/kw)	Speed of Mixer (rpm)
50L	61L	3×2kw	95L	350	550	750	824 ×2015	XL-0.55-4-23	1450/0.55	63
100L	120L	6×2kw	120L	500	700	820	1004×2120	XL-1.1-4-23	1450/1.1	63
200L	247L	6×3kw	200L	600	800	960	1108×2495	XL-1.5-4-23	1450/1.5	63
300L	355L	6×3kw	250L	700	900	1060	1208×2495	XL-2.2-4-23	1450/2.2	63
500L	589L	9×4kw	290L	900	1100	1280	1468×2695	XL-3-4-23	1450/3	63
1000L	1215L	12×4kw	560L	1200	1400	1640	1896×3110	XL-4-4-23	1450/4	63
2000L	2244L	15×5kw	750L	1400	1600	1980	2055×3500	XL-5.5-4-23	1450/5.5	63
3000L	3201L	15×5kw	1015L	1600	1800	2065	2165×3600	XL-7.5-4-23	1450/7.5	63
4000L	4020L	15×5kw	1226L	1600	1800	2065	2165 ×3800	XL-11-4-23	1450/11	63
5000L	5170	18×5kw	1440L	1800	2800	2265	2370×4000	XL-15-4-23	1450/15	63
