One end domed closed clear quartz glass tube
Quartz glass is the manufacture of special industrial technology with silica glass, is a very good base material. Quartz glass has an excellent range of physical and chemical properties. Such as:
1, high-temperature. Quartz glass softening point temperature of about 1730 degree Celsius, 1100 degree Celsiusunder long-term, short-term maximum temperature up to 1450 degree Celsius.
2.the corrosion-resistant. In addition to hydrofluoric acid, the quartz glass is almost not react with other acids and its acid capacity is 30 times the stainless steel of the ceramic 150. Especially in the chemical stability at high temperatures, is unmatched by any other engineering materials.
3, good thermal stability. A very small coefficient of thermal expansion of the quartz glass, and be able to withstand severe temperature changes, the quartz glass is heated to about 1100 degree Celsius, placed in water at room temperature and will not burst.
4, the light transmission properties. The quartz glass have good light transmission properties in the infrared spectral band, in the ultraviolet to visible light transmittance at 93% or more, particularly in the UV spectral region, the maximum transmittance of up to 80% or more.
5, good electrical insulation properties. Equivalent to one million times that of ordinary glass, the resistance value of the quartz glass is an excellent electrical insulating material also has good electrical properties, even at high temperatures.
Technical Date
|
Purity
|
SiO2:99.95-99.99%
|
|
Mohs hardness
|
7
|
|
Density
|
2.21 g/cm3
|
|
Annealing Poin
|
1215°C
|
|
Softening Point
|
1683°C
|
|
Maximum continuous operating temperature
|
1100°C
|
|
Maximum short-term working temperature
|
1300°C
|
|
Visible light transmittance
|
85-92%
|
Chemical Composition unit: ppm
|
Cr
|
Ge
|
Fe
|
Mg
|
Ti
|
Ca
|
AI
|
Na
|
Li
|
K
|
|
0.1
|
0.4
|
1.5
|
0.4
|
0.1
|
0.8
|
16
|
2.3
|
1.5
|
2.0
|
Lights Transmittance
|
nm
|
≤220
|
255
|
280
|
315
|
350
|
380
|
590
|
780
|
|
%
|
89
|
91
|
93
|
93
|
93
|
93
|
93.2
|
93.4
|
Our Advantage:
1. Cost price controlled well, lower price.
2. High precision.
3. Good quality, material: GE/HSQ, high purity, silica > 99.99% , high purity, silica > 99.99%.
4. High temperature-resistant, good corrosion-resistant and light transmittance.
5. Sample available.
6. Accept reworking if quality is not reach your requirements.
Application:
1. Chemical Industries
2. Electric Light Source
3. Laboratories
4. Medical equipment
5. Metallurgy
6. Optical
7. Photovoltaic
8. Photo communications
9. Research
10. Schools
11. Semiconductor
12. Solar
13. And more......
