Technical Parameters:

Technical Parameters	Unit	Model
		G2.5
Cyclic Volume(Vc)	dm³	1.0
Nominal Flow(qn)	m³/h	2.5
Max.Flow(qmax)	m³/h	4
Min.Flow(qmin)	m³/h	0.025
Total Pressure Loss	Pa	≤200Pa
Seal pressure	kPa	50
Max.Working Pressure	kPa	15
qmin≤q≤qt	%	±3
0.1qt≤q≤qmax	%	±1.5
Min.Reading	m³	0.001
Max.Reading	m³	99999.999
Working Temperature	ºC	-15~+55
Working Life	Year	12
Thread Size	mm	M30×2
		M26×1.5
Inlet-Outlet Space	mm	130
Weight	kg	2
Application	Synthetic Gas, Methane, Natural Gas, LPG

Product Features:

1,SOC design to achieve cost effectiveness and high reliability.
2,Unique encryption technique by MSP430 micro-controller to ensure data security.
3,Private handshake protocol for IC card info transmission to avoid data dropout and error message.
4,Sorting state identification mechanism to facilitate status identification and analysing.
5,Two-stage voltage alarm to facilitate battery condition monitoring.
6,7-bit LED to display gas volume info and prompting message even at standby status to ensure customer easily know gas usage.
7,Encrypted IC and as prepayment storage media to ensure low cost, magnetic resistance, safety and reliability.
8,Gain information by using bi-pulse, exposing to external magnetic field may lead to reduction of surplus gas volume and shut-off of the motor valve.
9,Unique password for each IC card, one-meter-one-card feature.
10,Compact design, ease of installation,can be integrated with computer system to achieve automatic gas sales management.
11,Working voltage:4.8v-6.5v, static working current:25µA, dynamic working current:350mA.
12,Impulse constant: 0.1 cubic meter per pulse.
13,Max prepaid gas volume: 9999 cubic meters.
14,All diaphragms are imported from overseas to ensure high product quality and performance.

Company Introduction:

Liaoning Hangyuxing IoT Instrument Technology Co., Ltd.Is a private shareholding company developed from the Gas Meter Factory of AVIC Shenyang Liming Aero-Engine Group Co.,Ltd through re-organization in 2004.By inheriting the technology,management and engineering experts from the previous company, Liaoning Hangyuxing IoT Instrument Technology Co., Ltd.Has established business relationship with China National Measuring Science Research Institute and leading gas meter manufacturers in Japan and .

Liaoning Hangyuxing IoT Instrument Technology Co., Ltd., targeting to be the pioneer of gas meter industry business, remains committed to the management philosophy of people foremost and sci-tech innovation.Through years of stable development, Liaoning Hangyuxing has become a hi-tech company that integrates research, development, manufacturing and marketing as a whole.Now Liaoning Hangyuxing has a total employee of 220 including 32 R&D engineers.The company has been certified on ISO9001:2008,ISO14001-2004 and OHSAS18001-1999.The main products of Liaoning Hangyuxing are Mechanical Heat Meter, Ultrasonic Heat Meter, IC Card Gas Meter, Remote Control Gas Meter, Bi-module Gas Meter, Mechanical Water Meter, Remote Control Water Meter and IC Card Water Meter.Through continuous investment on production lines, now the manufacturing capacity is up to 1,000,000 sets a year.

Liaoning Hangyuxing IoT Instrument Technology Co., Ltd.Is always ready to serve customers with high quality product, competitive pricing and innovative solution.Adhering to the principles of integrity, expertise and enthusiasm, Liaoning Hangyuxing is willing to establish business relationship with customer from all over the world on the basis of mutual benefit and common development.
